AG1-PH65-08M1

Compressor Pump: Quality cast iron single stage compressor · Durable stainless-steel braided discharge hose for longer life · Splash lubricated cast iron crankcase to extend the hours of performance · Cast iron head for heat dissipation · Large canister intake filter

Generator: Brushless alternator · Industrial 1800-watt generator with two NEMA 5-20R receptacles · Total harmonic distortion (THD) less than 5% · 100% copper windings

Engine: Industrial Honda GX200 OHV engine

Frame: Powder coated 8-gallon twin tank receivers · 3/16-inch base plate to reduce vibration · 14-gauge powder coated two-piece belt guard with 1/4-turn release for quick access to belts · Convenient lifting handles

Components: Regulator and two gauges for tank and outlet pressure · Manual drain valves for proper maintenance · 12-inch flywheel for extra cooling and longer life · Quality pilot valve unloader · Belt tightening system pulls engine straight to ensure constant belt alignment

Specifications

CFM @ 90 PSI	12.4
CFM @ 125 PSI	10.9
Alternator Wattage/Maximum Output	1800 watts
Alternator Wattage/Continous with Compressor On-Load	600 watts
Alternator Wattage/Continous with Compressor Off-Load	1600 watts
Receptacles	(2) NEMA 5-20R
Displacement/Engine	196cc Honda GX200 OHV
Compressor	Single stage, cast iron
Mobility	Portable Air Compressor/Generators
Stage	Single Stage Air Compressor/Generators
